Ricoh 35 EFS

Ricoh 35 EFS Konica built this camera as part of their long-running range finder and view finder compact camera series. Exposure is fully automatic and flash is built in.

Foam seals are the only known weakness of this camera so before you spool your first roll of film in, make sure to check the seals first. As for the rest, it seems to be a pretty sturdy camera.

Specifications
Manufacturor  :  Ricoh Company Ltd.
Model  :  Ricoh 35 EFS
Type  :  Range finder compact camera
Produced  :  1980
K.D. Müller Reference  :  K103255
Film  :  35 mm, type 135
Picture size  :  24 x 36 mm
Made in  :  Taiwan R.O.C.
Quantity Made  :
Original List Price  :
Material  :  metal partly covered with black plastic
Lens  :  Color Rikenon 1:2.8 40mm. 4 elements in 3 groups.
Filter size  :  46 mm
Focusing  :  Manual zone focussing with scales in meter, foot and pictograms
Focus range  :  0,9 m - infinity
Viewfinder  :  View finder with parallax correction marks, F-stop scale, exposure meter needle and unterexposure warning. 85% coverage, magnification 0.5x
Shutter  :  mechanical shutter 1/125.
Aperture  :
Self timer  :  yes
Exposure  :  Fully automatic
Exposure meter  :  Built in CdS meter
Film speed setting 25 - 400 ASA
Battery  :  One Mercury type 675 button cell for operation plus 1 AA for flash. The 675 should last for at least one year according to the manual.
Flash  :  Built in flash which may be manually switched on.
Flash Contact  :  none
Film Advance  :  manual, short single stroke lever on top
Other  :
Dimensions  :  130 x 55 x 80 mm (l x w x h)
Weight  :  390 gram w/o batteries.
Body serial number  :  38 501886
4090 stamped in film compartment
Collection status  :  to be sold
Ricoh 35 EFS

links Ricoh 35 EFS weblinks
links Instruction manual at Butkus
links Instruction manual at Butkus.
